Transfer to Unit and Commissioning
6-10
• If a warning occurs in the positioning unit, click [Clear warning] to clear the
warning.
• This dialog cannot be closed while the positioning unit is in JOG operation.
Dialog box items
Items Description
Current value
Monitors the feedback values after the unit system conversion for each axis.
Click [Present Value Refresh] to display the dialog for inputting value to change the present
value.
Unit
Monitors the unit of positions specified with parameter settings on an axis-by-axis basis on
the positioning unit.
Deviation (Pulse)
Monitors the deviation of the amount of movement while the auto check function for the
amount of movement is activated.
JOG target speed
Monitors and displays the target speed in the JOG operation. Click [Change] to change the
target speed for the JOG operation.
JOG [+] Click [+] to perform the forward rotation.
JOG [-] Click [-] to perform the forward rotation.
Axis state The operating states of axes or error and warning occurrences.
Error code The latest error code if an error occurs.
Clear errors Clears the error by clicking this button if an error occurs.
Warning code Indicates the latest warning code if a warning occurs.
Clear warning Clears the warning by clicking this button if a warning occurs.
Speed factor
The target speed of the home return specified in the parameter settings for each axis is
regarded as 100%, and the operation is executed at the specified speed rate. Clicking
[Speed factor] shows the dialog for inputting the value.
