Troubleshooting the Anesthetic Gas Module 9 Anesthetic Gas Module
205
The second flow chart continues from the first at the point A “Communication Problem”.
Figure 46 Troubleshooting - Communication Problems
A
Communication
problem from the
beginning. (LED steadily
on)
Communication problem occurs
during operation, indicated by
flashing LED and INOP
GA
EQUIP MALFUNCT.
Checks to perform.
Check that the Anesthesia
SW bundle #H30 is
installed on the monitor.
(Set monitor into Standby
mode and check for
“IntelliVue Anesthesia
#H30”).
If not order upgrade to
Anesthesia SW.
Check for correct RS232
config and correct MIB
port. Correct the settings if
necessary.
Check for proper physical
connections/cables (see
chapter 2).
Connect and run AGM on
other IntelliVue monitor.
Problem
Done
Problem
fixed
Communication
Troubleshoot original
not fixed
Still communication
problem
problem fixed
IntelliVue monitor
• follow trouble-
shooting table
Power Supply
Diagnostic
Checks
• check all internal
cables for damage /
loose fit
if that does not help,
replace the motherboard
To Next Page
