Philips IntelliVue MP70 Service Manual

9 Anesthetic Gas Module Troubleshooting the Anesthetic Gas Module
206
The third flow chart continues from the first, from the point B “Measurement-type Problem - No
INOP”.
Figure 47 Troubleshooting - Measurement Problems with No INOPS
Flow charts illustrated in Figure 48 and Figure 49 follow on from here.
B
Gas measurement accuracy
problems, incorrect values
Automatic agent
identification
problems.
O2 is not measured
Disappearing wave
s
Check accessories for leaks,
kinks and other damages.
Replace if necessary.
Check connections for
blockages. If any, remove
them.
Use Calibration gas
(M1660A) in SERVICE
MODE (not in Monitoring
mode) and perform a
complete calibration check
of suspect channels(s). (incl.
leakage and flowrate checks)
Calibration
check failed
Calibration
check passed
Perform a full calibration
Follow troubleshooting
table Calibration Checks
for failed calibrations.
Check if sample line is con-
nected. If not, connect it.
Check on IntelliVue if
parameter O2 is on.
If not, turn it on.
DONE
DONE
DONE, AGM
measures correctly.
DONE, AGM
measures correctly.
Problem
not fixed
Problem fixed
Calibration
failed
Calibration
passed
C
D
Problem fixed
Problem
not fixed
Follow troubleshooting
table O2 Assembly
Diagnostic Checks.
Agent is not measured
Check if sample line is con-
nected. If not, connect it.
Check on IntelliVue if
parameter Agent is on.
If not, turn it on.
DONE
Problem fixed
Problem
not fixed
Follow troubleshooting
table Agent ID Assembly
Diagnostic Checks.
