Additional settings as well as features and what you need to know about the RFC 4072S
108580_en_02 PHOENIX CONTACT 163 / 272
7 Additional settings as well as features and what you
need to know about the RFC 4072S
7.1 Resetting the controller to the default settings
• Open the “CONFIG DETAILS” menu.
• Select the “MAINTENANCE” menu item in the “CONFIG DETAILS” menu.
• Select the “FACTORY RESET” menu item in the “MAINTENANCE” menu.
Figure 7-1 “FACTORY RESET” menu
• Start the reset process by tapping the symbol (A in Figure 7-1).
• Acknowledge the “Reset to default! Are you sure?” dialog by tapping on the sym-
bol (B in Figure 7-1) again.
The RFC 4072S is restarted after the resetting process. The display then shows the follow-
ing:
Figure 7-2 Default settings of the RFC 4072S: indication on the display
