LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
(Continued on next page)
A03 Power Module A04 Therapy PCB A07 Battery
Code Service Code Description Corrective Action
5105 Battery failed to reach charge in 2.5 hours 1. Replace the A07 Battery
2. Replace the A03 Power module
5106 Power supply out of tolerance 1. If power supply voltage is <14 Vdc, replace
A03 Power module
2. If >14 Vdc, clear error and perform PIP
5107 Power module RAM error Replace the A03 Power module
5108 Power module self-test service code Replace the A03 Power module
510a Battery <10 V after 20 minutes of charging 1. Replace the A07 Battery
2. Replace the A03 Power module
510b Does not switch to battery power Replace the A03 Power module
510c Does not detect ac disconnect Replace the A03 Power module
510d Battery powered when connected to ac power Replace the A03 Power module
510e Battery <10 V after charge cycle Replace the A07 Battery
6-27
