LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
(Continued on next page)
A03 Power Module A07 Battery
Code Service Code Description Corrective Action
510f Battery charge cycle stopped 1. Check battery connection
2. Replace the A07 Battery
3. Replace the A03 Power module
5110 AC isolation diode shorted Replace the A03 Power module
5112 Battery not detected 1. Check the A07 Battery connection
2. Check W08 Battery Cable
3. Check for valid power hardware ID in
SERVICE/STATUS/DEVICE DATA overlay
4. Replace the A07 Battery
5. Invalid power hardware ID; replace the
A03 Power module
6. Valid power hardware ID; replace the
A04 Therapy PCB
6-28
