LIFEPAK 20/20e Defibrillator/Monitor Troubleshooting
Service Code Table (continued)
Code Service Code Description Corrective Action
5115 Battery thermistor <400 Ohms Replace A07 Battery (LIFEPAK 20e)
Ohm measurement of white wires of A07 Battery
(battery thermistor LIFEPAK 20)
■ Replace the A07 Battery if <400 Ohms
■ Replace the A03 Power module if >400 Ohms
5116 Charger reporting zero during battery charging Replace the A03 Power module
5117 No 12C connection detected
(LIFEPAK 20e only)
1. Replace the A07 Battery
2. Replace the A03 Power module
5118 Power module connected to NiMH battery
(LIFEPAK 20 only)
Replace the A07 Battery
511a Battery failure Replace the A07 Battery
5fff Additional information related to error code that is
logged before 5fff
No action required for 5fff; refer to error code
logged before 5fff
6-29
