LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Front Case (continued)
A05 User Interface (UI)
PCB Installation
(continued)
3. Place the two grounding harnesses (221) onto the new lower left and right
4-40 0.312 screws (173); torque to 6.8 in-lb.
4. Install four new 4-40 0.312 screws (173) onto the A05 UI PCB; torque to
6.8 in-lb. Refer to Grounding Harness Orientation for grounding harness
placement.
Note: Replace any broken or frayed grounding straps.
5. Install the Speed Dial connector to the A05 UI PCB at J32.
6. Connect the W18 UI Flex Cable to the A05 UI PCB at J31.
7. Complete the process by Installing the active display assembly.
Parts List Interconnect Front Case View Rear View Main Assemblies
9-54
