LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Boardstack (continued)
Boardstack Removal
(continued)
12. Disconnect the W05 SpO2 Flex Cable from the A06 OEM/SpO2 Assembly at
J54 by first removing the screw (255) using a 3/32 allen driver.
13. Disconnect the W06 ECG wire harness from the A02 PP PCB at J23.
14. Disconnect the W25 Speaker Harness Extension Cable from the
A01 System PCB at J5.
15. Lift the boardstack assembly away from the bottom case.
16. Disconnect the A14 Inductive Resistor’s cable from the A04 Therapy PCB
at J1.
17. Remove and discard the two 4-40 0.312 screws (173) that connect the A14
Inductive Resistor to the EMI shield (274) and PCB support bracket (139).
18. Remove the boardstack assembly from the bottom case.
CAUTION
Possible component damage. The OEM/SpO2 flex cable is secured to
locking posts. Remove the plug and the locking post simultaneously to avoid
damage to the connector.
Parts Lists Interconnect System View Therapy View Main Assemblies
9-74
