LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Bottom Case (continued)
A12 Printer Module
Removal (continued)
Note: If removing the A12 Printer, the removal process is complete. If
removing the printer shroud or the W14 Printer Flex Cable, continue with the
removal process until the desired part is removed.
5. Slide the printer bezel (83) up and away from the bottom case.
6. Remove and discard the three 4-40 0.312 screws (173) from the bottom of
the printer shroud (89).
7. Carefully lift the shroud to access the 4-pin power cable.
8. Disconnect the 4-pin power cable from the A03 Power Module at J45, and
feed it through the small shroud cutout.
9. Feed the 4-pin power cable and the W14 Printer Flex Cable through the
large shroud cutout.
10. Remove the printer shroud (89) from the bottom case.
11. Lift the W06 ECG Cable out of the way and carefully remove the W14 Printer
Flex Cable from the bottom case. The cable is held in place by adhesive, so
it should be removed evenly to avoid damaging the connectors or the cable.
Parts List Interconnect Diagram Module View Connectors View Main Assemblies
