LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures

Service Replacement Kits (continued)

KIT-REPAIR, POWER

MODULE, LIFEPAK 20e

MIN 3202718-039

(RoHS) or

3202718-022

(non-RoHS)

Item Quantity MIN CAT. Part Description

A03 1 3317740-000

(RoHS)

Power Supply module

A03 1 3202131-009

(non-RoHS)

Power Supply module

W08 1 3206579 Battery Cable LIFEPAK 20e

W10 1 3206857 Power/Therapy Cable,

LIFEPAK 20e

W11 1 3201997 ECG Sync/System Cables

W13 1 3206469 AC Power Cable, LIFEPAK

20e

9-190
