LIFEPAK 20/20e Defibrillator/Monitor Replacement Procedures
Service Replacement Kits (continued)
KIT-REPAIR, LED DISPLAY
FOR UI 3317230-000 (RoHS)
and 3201966-007 (non-RoHS)
- LED Display and Backlight
for Redux UI PCB 3317230-
000 (RoHS) or 3201966-
007(non-RoHS) or greater
(requires Redux level
PCBsoftware set)
MIN 3202718-032
Item Quantity MIN CAT. Part Description
A08 1 3308907 Module-OEM, LED Driver
(Backlight Inverter)
A11 1 3309555 Active Display, Color LED
W15 1 3300152-000 21300-007774 Active Display Cable
43 1 3200913-003 21300-004233 Display lens
47 1 3200640-015 21300-004838 Active Display Bracket
173 4 202253-761 21300-001038 Screws 4-40 x 0.312
266 1 3205497-308 21300-006141 Nylon snap rivet
9-198
