Appendix C: TARGA 3000 Technical Specifications
Component
(Y, B-Y, R-Y) -- 8 bit, 4:2:2 spatial resolution
-- Input gain and offset controls
*
Y 1.0 V p-p, 75 Ω BNC
*
B-Y +/- 350mV p-p, 75 Ω, BNC
*
R-Y +/- 350mV p-p, 75 Ω, BNC
Genlock Reference -- Input is 1Vpp, 75 Ω, BNC (REF)
Supported Formats: -- Composite (NTSC, NTSC-J, PAL)
-- S-Video (NTSC, NTSC-J, PAL)
-- Y,B-Y,R-Y (NTSC Betacam, NTSC Betacam-J, SMPTE/EBU)
Video Output
Supported Formats -- Composite (NTSC, NTSC-J, PAL)
-- S-Video (NTSC, NTSC-J, PAL)
-- Y,B-Y,R-Y (NTSC Betacam, NTSC Betacam-J, SMPTE/EBU)
CV, Y/C -- Interpolates 8 bit data path to a 10 bit DAC resolution
-- Supports NTSC, NTSC-J and PAL
-- Output phase control
*
CV 1.0 V p-p, 75 Ω, BNC
*
S-Video Y: 1.0V p-p
C: 627mV p-p
4-pin DIN
Component
(Y, B-Y, R-Y) -- Interpolates 8 bit data path to a 10 bit DAC resolution
-- Output gain offset & saturation control
*
Y 1.0 V p-p, 75 Ω, BNC
*
B-Y +/- 350mVp-p, 75 Ω, BNC
*
R-Y +/- 350mVp-p, 75 Ω, BNC
* Levels are based on NTSC 100% white, 75% fully saturated bars.
