163Pinnacle Systems TARGA 3000
Audio Input
Balanced Inputs -- Channel 1 (left) 1 x XLR, line level, +4dBu, nominal
-- Channel 2 (right) 1 x XLR, line level, +4dBu, nominal
-- Headroom 20 dBu above nominal
-- Input Impedance 10 kΩ
-- 24 bit ADC resolution
-- Audio to Video Sync < 1mS
-- Sample Rate 48 kHz
Unbalanced Inputs -- Channel 1 (left) 1 x RCA, -10 dBu, nominal
-- Channel 2 (right) 1 x RCA, -10 dBu, nominal
-- Headroom 28 dBu above nominal
-- Input Impedance 20 kΩ
-- 24 bit ADC resolution
-- Audio to Video Sync < 1mS
-- Sample Rate 48 kHz
Audio Output
Balanced Outputs -- Channel 1 (left) 1 x XLR, line level, +4dBu nominal to 600 Ω load
-- Channel 2 (right) 1 x XLR, line level, +4dBu nominal to 600 Ω load
-- Headroom 20 dBu above nominal
-- 24 bit DAC resolution
Unbalanced Outputs -- Channel 1 (left) 1 x RCA, -10 dBu nominal
-- Channel 2 (right) 1 x RCA, -10 dBu nominal
-- Headroom 28 dBu above nominal
-- 24 bit DAC resolution
