Polaris 2015 RZR 900 Service Manual

4.10
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
4. With the ignition turned off, disconnect the wire
harness from the ECU. Lift the connector locking
levers and rotate them up until the connectors are
free from the ECU.
NOTE: Upon removing the ECU connectors, you
should hear a “click” when the connectors are
fully open.
5. Remove the ECU from the vehicle.
6. To install, reverse the procedure and tighten the ECU
mounting screws to specification.
ECU Mounting Screws:
24 in-lb (3 Nm)
NOTE: Upon installing the ECU connectors, you
should hear a “click” when the connectors are
fully closed.
FUEL SYSTEM
