Polaris 2015 RZR 900 Service Manual

8.4
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
Tie Rod Replacement
1. Safely lift the vehicle.
2. Remove the four wheel nuts.
3. Remove the fastener
1
retaining the tie rod end to
the knuckle.
4. Mark the location of the tie rod jam nut
2
on the tie
rod. Loosen the tie rod jam nut and unthread the tie
rod end off the tie rod.
5. Install new tie rod end and thread it back to the
original location of the other tie rod end. Tighten jam
nut to specification.
Tie Rod Jam Nut:
14 ft-lbs (19 Nm)
6. Install the tie rod end into the knuckle. Tighten new
fastener to specification.
Tie Rod End to Knuckle:
30 ft-lbs (41 Nm) + 90°
7. Install the wheel and four wheel nuts. Tighten lug nuts
to specification.
Wheel Lug Nuts:
Aluminum: 120 ft-lbs (163 Nm)
Steel: 60 ft-lb (81 Nm)
STEERING / SUSPENSION
