PVT Assembly
1. Install the inner clutch cover in the vehicle.
2. Install the seven fasteners retaining the inner clutch
cover to the engine and transmission. Torque to
specification.
Inner Clutch Cover Fasteners:
10 ft-lb (14 Nm)
3. Install the Drive Clutch. Torque mounting bolt to
specification.
Drive Clutch Bolt:
96 ft-lb (130 Nm)
4. Install the Driven Clutch. Torque mounting bolt to
specification.
Driven Clutch Bolt:
38 ft-lb (52 Nm)
5. Install the drive belt.
6. Install the PVT intake and exhaust ducts to the inner
clutch cover. Torque clamps to specification.
Duct Clamps:
12 ft-lb (16 Nm)
7. Install the eight screws retaining the outer clutch
cover. Torque screws to specification.
Outer Clutch Cover Screws:
54 in-lb (5 Nm)
