Polaris 2015 RZR 900 Service Manual

5
5.7
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
PVT Disassembly
1. Remove the eight screws
1
retaining the outer clutch
cover.
2. Remove the PVT intake and exhaust ducts by
loosening the clamps
2
retaining the ducts to the
inner clutch cover.
3. Remove the drive belt. (see Chapter 5 – Belt
Removal, page 5.9)
4. Remove the Driven Clutch retaining bolt
3
.
5. Remove the Drive Clutch retaining bolt
4
.
6. Remove the seven fasteners retaining the inner
clutch cover to the engine and transmission.
7. Remove the inner clutch cover from the vehicle.
PVT SYSTEM
