Polaris 2015 RZR 900 Service Manual

6.4
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
SHIFT LEVER / CABLE
Shift Lever Removal
1. Remove the shift knob cover
1
, retaining screw
2
and shift knob
3
from the shift lever
4
.
Remove the screws retaining the center console
using a T27 and T30 Torx driver. Remove the console
from the vehicle.
2. Remove the clip and washer retaining the shift cable
to the shift lever and disconnect the cable end from
the lever.
3. Remove the retaining ring
5
and slide the shift lever
6
off the mounting bracket and out from the frame.
4. Remove both bushings
7
from the shift lever and
service as needed.
Shift Lever Installation
Perform the removal steps in reverse order to install the
gear shift lever (lever, cable, console, shift knob).
TRANSMISSION
