Polaris 2015 RZR 900 Service Manual

6.2
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
GENERAL INFORMATION
Torque Specifications
ITEM
TORQUE VALUE
Bell Crank Nut
18 ft-lb (24 Nm)
Differential Cover
Screw
22 ft-lb (30 Nm)
Engine / Transmission
Mounting Bolts
Step 1-2: 64 ft-lb (87 Nm)
Step 3: 5 ft-lb (7 Nm)
Step 4-7: 44 ft-lb (60 Nm)
Gear Sector Cover
12 ft-lb (16 Nm)
Park Flange Screws 10 ft-lb (14 Nm)
Snorkel Tube
Refer to Transmission
Assembly / Snorkel Gear
Backlash Procedure, page
6.25
Shift Cable Bracket
Bolts
17 ft-lb (23 Nm)
Shift Fork Screws
10 ft-lb (14 Nm)
Snorkel Tube Locking
Screw
10 ft-lb (14 Nm)
Speed Sensor Screw 12 ft-lb (16 Nm)
Stabilizer Bar Linkage
(Rear)
40 ft-lbs (54 Nm)
Transmission Case
Screws
20 ft-lbs (27 Nm)
Transmission Fill /
Drain Plugs
14 ft-lbs (19 Nm)
Transmission Mount
Bracket Fasteners
(rear)
22 ft-lb (30 Nm)
Transmission Mount
Isolator Bolt (rear)
33 ft-lb (45 Nm)
Transmission Snorkel
Tube Locking Screw
10 ft-lb (14 Nm)
Special Tools
PART NUMBER TOOL DESCRIPTION
PA-50231 Snorkel Tool
2871698
(Part of 2871702 Kit)
Rear Output Seal Driver
2871699
(Part of 2871702 Kit)
Rear Driveshaft Seal Guide
2871282
Bearing Seal Driver (50 mm)
PU-50566 Transmission Nut Socket
PU-50658 Clutch Center Distance Tool
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
Lubrication Specifications
Recommended Transmission Lubricant:
AGL (PN 2878068) (Quart)
Capacity (Standard): 44 oz. (1300 ml)
Capacity (INT’L): 40.5 oz. (1200 ml)
TRANSMISSION
