7.15

9925723 R01 - 2015 RZR 900 Service Manual

• Be sure joints are thoroughly clean and that the

proper amount and type of grease is used to refill

when joint boots are replaced and when joints are

cleaned. Refer to text for grease capacity of CV

joints and CV joint boots.

Outer CV Joint / Boot Replacement

1. Use a side cutters to cut and discard the boot clamps

2. Remove the large end of the boot from the CV joint

and slide the boot down the shaft.

3. Clean the grease from the face of the joint.

4. Place the drive shaft in a soft-jawed vise. Using a

soft-faced hammer, or brass drift, strike the inner

race of the joint to drive the joint off the drive shaft.

Be sure to tap evenly around the joint to avoid

binding.

IMPORTANT: Tap on inner race only!

5. Make sure circlip

is on the shaft and not left in the

joint.

FINAL DRIVE
