Polaris 2015 RZR 900 Service Manual

10
10.13
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
Rear Bumper Removal
1. Disconnect the harness connectors at the tail lights.
2. Remove the zip ties retaining the harness to the rear
bumper.
3. Remove the seven (two lower and five upper) T-27
Torx screws retaining rear bumper to the cargo box.
4. Remove rear bumper from vehicle.
Hood Removal
1. To remove the hood, turn both 1/4 turn latches
1
to
disengage the rear portion of the hood.
2. Lift rear of hood and slide forward to disengage the
front tabs and remove the hood from the vehicle.
Upper Dash Removal
1. Remove the hood as previously described.
2. Remove the two T-40 Torx screws retaining the
Upper Dash cover between the front fenders
2
.
3. Disconnect the instrument cluster, AWD switch,
headlight switch, and ignition switch. Note their
location and wire routing. Remove the upper dash.
Lower Dash Removal
1. Remove the Upper Dash (see Chapter 10 – Upper
Dash Removal, page 10.13
2. Remove the two T-40 Torx screws retaining the dash
and the one T-40 retaining the back of the dash to the
bracket.
3. Remove the dash assembly from the vehicle.
NOTE: The lower dash is also held by clips. Pull
the dash straight out to disengage the clips..
BODY / FRAME
