Polaris 2015 RZR 900 - Fuel System Assembly View

4
4.5
9925723 R01 - 2015 RZR 900 Service Manual
© Copyright 2014 Polaris Industries Inc.
Fuel System Assembly View
1
Electronic Control Unit (ECU)
7
Fuel Pump/Regulator
2
Crankshaft Position Sensor (CPS)
8
Fuel Level Sender
3
Engine Coolant Temperature Sensor (ECT)
9
Fuel Filter
4
Throttle Body/Electronic Throttle Control (ETC)
10
Fuel Supply Line
5
Fuel Injectors
11
TMAP Sensor
6
Fuel Rail/Regulator
12
Engine Coolant Temp Sensor
FUEL SYSTEM
