9.15

9925723 R01 - 2015 RZR 900 Service Manual

Parking Brake Disc

Disc Inspection

Measure the brake disc with a micrometer. If the

thickness of the disc is less than specified, replace the

brake disc (see Chapter 9 – Disc Replacement, page

Disc Replacement

1. Remove the parking brake caliper from the disc (see

Chapter 9 – ).

2. Using a 1/2″ socket and ratchet, remove the brake

disc retaining bolt and flat washer.

3. Remove the disc from the transmission shaft.

4. Install the new brake disc. Install the mounting bolt

and flat washer. Torque the mounting bolt to

specification.

Parking Brake Disc Mounting Bolt:

14 ft-lb (20 Nm)

BRAKE SYSTEM

Polaris 2015 RZR 900 Service Manual
