9925723 R01 - 2015 RZR 900 Service Manual

7. Install (-) negative battery cable to the upper starter

mounting bolt / stud. Torque nut to specification.

Starter Mounting Bolts and Nut:

7 ft-lb (10 Nm)

Starter Solenoid

Starter Solenoid Bench Test

Test the start solenoid by powering the solenoid using

battery voltage for a maximum of 5 seconds. With the

solenoid energized, resistance should read about 0 - 0.5

ohms between terminals (A) and (B). If resistance

measurement is out of specification, replace the starter

solenoid

Starter Solenoid Operation

To energize the Starter Solenoid the following must

occur:

• The brake must be applied to provide a ground

path via the orange wire.

• The key switch must be turned to the “start”

position to provide 12V power via the Green /

White wire.

• Once the pull-in coil is energized, the solenoid

provides a current path for 12V power to reach the

starter motor.

NOTE: See “ELECTRICAL SYSTEM

BREAKOUTS: Starter-Interlock” provided in

this chapter for starter solenoid operation.

ELECTRICAL

Polaris 2015 RZR 900 Service Manual
