Quantum Scalar i6000 User Manual

Chapter 2: Troubleshooting Your Library
Interpreting LEDs
108 Quantum Scalar i6000 User’s Guide
LBX Terminator Version 2 LEDs
The LBX terminator has six blue LEDs that indicate the presence of
modules in the library.
Figure 32 shows the locations of the LEDs.
Tab l e 20 on page 109 describes how to interpret LED activity on the LBX
terminator.
On Off Off On Off On The library has one control module and five expansion modules.
On Off Off Off On Off The library has one control module and six expansion modules.
On Off Off Off Off On The library has one control module and seven expansion modules.
On On Off Off Off Off The library has one control module and eight expansion modules.
On On Off On Off Off The library has one control module and nine expansion modules.
On On Off On On Off The library has one control module and ten expansion modules.
On On Off On On On The library has one control module and eleven expansion
modules.
On On Off Off On On The library has one control module and twelve expansion
modules.
On On Off On Off On The library has one control module and thirteen expansion
modules.
On On Off Off On Off The library has one control module and fourteen expansion
modules.
On On Off Off Off On The library has one control module and fifteen expansion
modules.
LED On/Off Combinations
Explanation123456
