Table 3-1. Current Draw of IMUX Modules Versus Power Supply Capacity For M-DACS Shelf
Module +5V +15V
Operating
-15V
Operating
Number
Per system
Watts@
+5V
Watts@
Operating +15V
Watts@
-15V
Watts/
card
CM4 0.500 0.000 0.000
DACS Module 1.100 0.000 0.000
DS-562I 0.140 0.000 0.000
DS-64NC 0.329 0.000 0.000
DS-961D 0.107 0.034 0.034
DA-191A 0.067 0.000 0.000
DA-191B 0.067 0.000 0.000
DA-91I 0.080 0.000 0.000
DA-121I 0.080 0.000 0.000
NCM 0.081 0.000 0.000
VF-5A 0.060 0.030 0.013
VF-5C 0.120 0.070 0.050
VF-6I 0.027 0.016 0.019
VF-8A 0.074 0.031 0.024
VF-15C 0.072 0.049 0.027
VF-16B off hook 0.209 0.094 0.000
VF-16B max ring 0.255 0.450 0.000
VF-16B ring 0.158 0.110 0.000
MTS 0.134 0.000 0.000
MTS I/O 0.080 0.080
Status (no output) 0.140 0.010 0.000
Status (8 output) 0.140 0.100 0.000
Status (16 output) 0.140 0.200 0.000
Telemetry TX 0.060 0.080 0.080
Telemetry RX 0.050 0.100 0.100
Telemetry RX 0.081 0.000 0.000
SAG Module 0.140 0.000 0.000
MA-402 0.044 0.000 0.000
MA-490 0.140 0.000 0.000
MA-235 0.240 0.000 0.000
107455-201 0.240 0.080 0.060
107455-301 0.240 0.050 0.050
107455-401 0.135 0.060 0.050
107455-501 0.135 0.060 0.050
107455-410 0.135 0.060 0.050
Supply +5V +15V -15V watts@volts
Rating (Amps) 4.50 0.75 0.75 amps@volts
1. If current draw exceeds 4.5 Amps from +5V supply, 0.75 Amps from +15V supply, or 0.75 Amps from –15V supply,
additional power supply capacity is required.
