Once the display is edited to the desired value, do the following:
1. Press down the SET/NEXT switch until the underscore disappears and the digits are again
displayed full size. For example, if the displayed address was changed to 040, the display now
reads 040. The red part of the ON/OFF indicator lights to show that the address displayed is
not the current address.
2. To change the multiplexer's network address to the number on the display, press up twice on
the SET/NEXT switch.
Pressing up once on the SET/NEXT switch causes the green part of the ON/OFF
indicator to blink; this shows that a change is about to be made. At this point
you can abort the change by pressing down on the SET/NEXT switch. Pressing up
on the SET/NEXT switch a second time actually makes the change. The green part
of the ON/OFF indicator now stays on and the red part turns off. This shows that
the displayed number is the currently-set address.
This procedure is illustrated in Table 4-7.
Ta
ble 4-7. Changing multiplexer network address from 001 to 040
Step Acti
on Function*
Display
ON/OFF
Indicator Status
1 Press up or down on the GROUP switch until "ADDR" is displayed. ADDR Both parts OFF.
2 Press down on the SET/NEXT switch once to display the current
address. The green part of the ON/OFF indicato
r will light
to indicate that the number on display is the current address setting.
001 Green (ON) part lit.
3 Press down on the SET/NEXT switch again to begin address editing. The first
digit will be blinking.
001 Green (ON) part lit.
4 Press down on the SET/NEXT switch to move the blinking to the
second digit.
001 Green (ON) part lit.
5 Press up four times on the SET/NEXT switch to change the center digit from
"0" to "4."
041 Green (ON) part lit.
6 Press down on the SET/NEXT switch once to move the 041 Green (ON) part lit.
blinking to the last digit.
7 Press up nine times on the SET/NEXT switch to change the last digit from
"1" to "0."
040 Green (ON) part lit.
8 Press down on the SET/NEXT switch once to restore the full-size display.
The red part of the ON/OFF indicator will light to indicate that the number on
display is
not
the current address setting.
040 Red (OFF) part lit.
9 Press up twice on the SET/NEXT switch to change the current address to
match the display. After the second switch press, the red part of the ON/OFF
indicator will turn off, and the green part will light. This means that the
address on the display is the current address.
040 Green (ON) part lit.
Note: The underscored digit indicates that it is blinking
M-DACS-T1 RFL Electronics Inc.
July 18, 2008 4-13 (973) 334-3100
