5.5.3 GETTING STARTED
Figure 5-9 shows a simplified drawing of the network that will be used for this example. Figure 5-10
shows a more detailed drawing of the network showing all IMUX 2000 M-DACS components,
modules, cards and cables used in the network example.
Figure 5-9. Basic drawing of the network used in the example
The network used in this example has 5 M-DACS nodes. Data and voice circuits are established
between node 1 and node 3, which consist of one phone line, one RFL 9300 charge comparison system
data link, and one RFL 9745 teleprotection data link. Table 5-1. lists the modules and cards in each
node that must be configured into the network.
Table 5-1. List of modules and cards used in the example that must be configured into the network
Node 1 Node 2 Node 3
4
3
2
5
PHONE
9300
9745
9745
9300
PHONE
PC OR
LAPTOP
1
Node 4 Node 5
DACS Module DACS Module DACS Module DACS Module DACS Module
CM4-1 CM4-1 CM4-1 CM4-1 CM4-1
CM4-2 CM4-2 CM4-2 CM4-2 CM4-2
VF5C VF5C
VF16B VF16B
DS562I DS562I
M-DACS-T1 RFL Electronics Inc.
February 28, 2006 5-14 (973) 334-3100
