Table 5-2. Status LEDs under NMS DACS Module Status Screen
NMS Label Description
DACS-R
General
Status
LINE Alert Amber LED: Indicates that a line fault has been detected.
HDW Alert Amber LED: Indicates that a hardware fault has been detected.
CNFG Alert
Amber LED: Is activated when the system is configured to operate in a
manner other than the normal protection function. Presently, only
turning service off or forcing a map is considered a configuration alert.
Port 1 Multi-color LED:
Green indicates that the received signal at Port 1 is good.
Amber indicates that the received signal at Port 1
contains errors insufficient to cause a switch, or
that the port is in the process of recovering.
Red indicates that the received signal at Port 1 is not
present or contains errors sufficient to cause a switch.
Port 2 Same as above for Port 2.
Port 3 Same as above for Port 3.
Port 4 Same as above for Port 4.
Port 5 Same as above for Port 5.
Port 6 Same as above for Port 6.
Port 7 Same as above for Port 7.
Port 8
Same as above for Port 8.
