Table 5-3 - continued. CM4 module parameters
CM4 Module
Group Parameter Description Legal Values Typical
Values
Alarms/Readings
(continued)
STANDBY COMMON MODULE TROUBLE
MAIN COMMON MODULE OFF VIA FIRMWARE
TO MAIN COMMON MODULE VIA MODE SWITCH
TO STANDBY COMMON MODULE VIA MODE SWITCH
TO MAIN COMMON MODULE VIA FIRMWARE
TO STANDBY COMMON MODULE VIA FIRMWARE
TRANSMITTER USING FTIME = <fallback timing> (FALLBACK TIMING)
PAYLD-LB = ON (PAYLOAD LOOPBACK ON)
LINE-LB = ON (LINE LOOPBACK ON)
EQPT-LB = ON (EQUIPMENT LOOPBACK ON)
SHELF NORMAL (Reading only)
Commands UNLOCK
LOCK
SET
CONFIG
CONFIG2
STATUS
STATUS2
WHO
NEXT
UPDATE
TIME
EVENT
VERSION
WARNING
CM4 configurations may vary depending on end user requirements. Activating the “Fcty”
Function described in Paragraph 5.11 will force settings to values shown in Tables 5-8 and 6-
2. These settings may not be the same as the end user requirements
