NOTE
Time Slot Sharing is only supported by software version SW200091I04 or later. To determine
the software version of the DA-91I in your system, remove the module from the multiplexer
chassis and read the label on device U1. The second line on the label is the software version.
The software label will be similar to the one shown below.
U1 5-17-01
SW200091I04
© ’01 RFL
SPECIFICATIONS
As of the date this Instruction Data Sheet was published, the following specifications apply to the RFL
DA-91I Asynchronous Data Polling Channel Module. Because all of RFL products undergo constant
improvement and refinement, these specifications are subject to change without notice.
Live Insertion/Extraction: The DA-91I is capable of live insertion and extraction into the IMUX
2000 shelf without interruption to the DS1 or any other DS0.
Asynchronous Data Interface:
Full duplex, one or two channel operation, two independent RS-232 data ports.
Data Rates:
One Channel operation: 0 bps to 19.2 kbps
Two Channel operation: 0 bps to 4.8 kbps
Time Slots: Both channels occupy one selectable DS0 time slot.
Jitter: Jitter rates shown below are proportionally lower for lower input rates:
At 4.8 kbps output data jitter is 20%.
At 9.6 kbps output data jitter is 20%.
At 19.2 kbps output data jitter is 35%.
RS-232 Interface:
Supports: Tx Data, Rx Data, Receive Line Signal Detect, Request to Send, Clear to Send,
Data Set Ready, Signal Ground.
Connector:
The DA-91I module requires the use of the MA-402I Module Adapter, which provides two
DB-9 connectors for the RS-232 interface.
Power Dissipation: 1 Watt nominal
RFI/EMI: C.37.90.2
MTBF (Calculated): Greater than 500,000 hours per Bellcore TR-332.
Operating Temperature: -20
o
C to +55
o
C (-4
o
F to +131
o
F).
Humidity: 0 to 95 %, non-condensing.
