RFL DA-121I RFL Electronics Inc.
February 10, 2000 7 (973)
334-3100
Table 2. SCB address settings, RFL DA-121I module
Module Address SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6
1 DOWN DOWN DOWN DOWN DOWN UP
2 DOWN DOWN DOWN DOWN UP DOWN
3 DOWN DOWN DOWN DOWN UP UP
4 DOWN DOWN DOWN UP DOWN DOWN
5 DOWN DOWN DOWN UP DOWN UP
6 DOWN DOWN DOWN UP UP DOWN
7 DOWN DOWN DOWN UP UP UP
8 DOWN DOWN UP DOWN DOWN DOWN
9 DOWN DOWN UP DOWN DOWN UP
10 DOWN DOWN UP DOWN UP DOWN
11 DOWN DOWN UP DOWN UP UP
12 DOWN DOWN UP UP DOWN DOWN
13 DOWN DOWN UP UP DOWN UP
14 DOWN DOWN UP UP UP DOWN
15 DOWN DOWN UP UP UP UP
16 DOWN UP DOWN DOWN DOWN DOWN
17 DOWN UP DOWN DOWN DOWN UP
18 DOWN UP DOWN DOWN UP DOWN
19 DOWN UP DOWN DOWN UP UP
20 DOWN UP DOWN UP DOWN DOWN
21 DOWN UP DOWN UP DOWN UP
22 DOWN UP DOWN UP UP DOWN
23 DOWN UP DOWN UP UP UP
24 DOWN UP UP DOWN DOWN DOWN
25 DOWN UP UP DOWN DOWN UP
26 DOWN UP UP DOWN UP DOWN
27 DOWN UP UP DOWN UP UP
28 DOWN UP UP UP DOWN DOWN
29 DOWN UP UP UP DOWN UP
30 DOWN UP UP UP UP DOWN
31 DOWN UP UP UP UP UP
32 UP DOWN DOWN DOWN DOWN DOWN
33 UP DOWN DOWN DOWN DOWN UP
34 UP DOWN DOWN DOWN UP DOWN
35 UP DOWN DOWN DOWN UP UP
36 UP DOWN DOWN UP DOWN DOWN
