Table 5. continued - Remote status messages (“S” codes) for a T1 or E1 system
S CODE Position Value Description
S2 B 0 0 0 0 0 0 0 0 1 Tx Channel 1 active
- - - - - - -
↑
TX CHANNEL 1
0 Tx Channel 1 inactive
B 0 0 0 0 0 0 0 0 1 Tx Channel 2 active
- - - - - - ↑ -
TX CHANNEL 2
0 Tx Channel 2 inactive
B 0 0 0 0 0 0 0 0 1 Tx Channel 3 active
- - - - -
↑ - -
TX CHANNEL 3
0 Tx Channel 3 inactive
B 0 0 0 0 0 0 0 0 1 Tx Channel 4 active
- - -
- ↑ - - -
TX CHANNEL 4
0 Tx Channel 4 inactive
B 0 0 0 0 0 0 0 0 1 Tx Channel 5 active
- - -
↑ - - - -
TX CHANNEL 5
0 Tx Channel 5 inactive
B 0 0 0 0 0 0 0 0 1 Tx Channel 6 active
- -
↑ - - - - -
TX CHANNEL 6
0 Tx Channel 6 inactive
B 0 0 0 0 0 0 0 0 1 Tx Channel 7 active
- ↑ - - - - - -
TX CHANNEL 7
0 Tx Channel 7 inactive
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
. . . Not used
