Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and speciﬁcations without notice.

RFL DA-291B RFL Electronics Inc.

April 13, 2010 11 (973) 334-3100

Input bit rate tolerance: -2.5% to +1%

Output bit rate tolerance: Start, data, parity bits

Nominal: ± 0.01%

Stop bit

Normal stop bit (Nom

inal): ± 0.01%

Redu

ced length stop bit: (Nominal -12.5%) ± 0.01%

Table 5. Setting Remote or Local Loopback

SW11 Switch Positions Function

SW11-1 Up

SW11-2 Up

Loopback Disabled

SW11-1 Down

SW11-2 Up

Remote Loopback

SW11-1 Up

Channel 1

SW11-2 Down

Local Loopback

The remaining Channels (2-4) are set in the same manner for SW11-3 through SW11-8
