Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and specifications without notice.
RFL DA-291B RFL Electronics Inc.
April 13, 2010 21 (973) 334-3100
Table 12. Remote Configuration Settings (P Codes)
P Codes Bits Used Switch
Equivalent
Value
(1)
Description
P0
B00000000
-------↑
1
Module in Service
SRVC OFF
0
Module Out of Service
P1/2/3/4
B00000000
--↑-----
TERM 1 Sets DI-A port to transmit (TX on A, RX on B)
per channel
0
Sets DI-B port to transmit (TX on B, RX on A)
Per channel
B00000000
---↑↑↑↑↑
TIME SLOT See
Table 13
Timeslot selection T1/E1 per channel
P5/6/7/8
B00000000
↑↑↑-----
BAUD
See
Table 14
Baud rate selection per channel
B00000000
---↑↑↑--
TS START
BIT
See
Table 14
Timeslot start bit selection per channel
B00000000
------↑↑
CHAR See
Table 14
Sets the number of bits per character, set for each
channel.
P9
B00000000
↑-------
ENABLE
CH1
1 Channel 1 enabled
0
Channel 1 disabled
B00000000
-↑------
ENABLE
CH2
1 Channel 2 enabled
0
Channel 2 disabled
B00000000
--↑-----
ENABLE
CH3
1 Channel 3 enabled
0 Channel 3 disabled
B00000000
---↑----
ENABLE
CH4
1 Channel 4 enabled
0 Channel 4 disabled
1. These are the only legal values for setting the parameters. Setting any parameter to a value outside its specified range
will produce an unpredictable result.
