Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and speciﬁcations without notice.

RFL DA-291B RFL Electronics Inc.

April 13, 2010 24 (973) 334-3100

Table 14. Data Port Configuration Via Remote Access

P5 thru P8 Settings for Data Rate for

Channel 1- 4

Maximum

Data Rate

Time Slot Capacity

B000xxxxx

600 bps 1/8 of one time slot

B001xxxxx

1.2 kbps 1/8 of one time slot

B010xxxxx

2.4 kbps 1/8 of one time slot

B011xxxxx

4.8 kbps 1/8 of one time slot

B100xxxxx

9.6 kbps 1/4 of one time slot

B101xxxxx

19.2 kbps 1/2 of one time slot

B110xxxxx

38.4 kbps Full time slot

P5 thru P8 Settings for Time Slot Start

Bit for Channel 1- 4

Time Slot Start Bit

Bxxx000xx

Bxxx001xx

Bxxx010xx

Bxxx011xx

Bxxx100xx

Bxxx101xx

Bxxx110xx

Bxxx111xx

P5 thru P8 Settings for Number of Bits

per Character for Channel 1- 4

Number of Bits per Character

Bxxxxxx00

Bxxxxxx01

Bxxxxxx10
