RFL DS-562I RFL Electronics Inc.
June 14, 2007 15 (973) 334-3100
Table 7. Controls and indicators, DS-562I
Item Name/Description Function
1 LED indicator (green) ADR EN: Lights when the transmit address is enabled (not set to 0). Used in 56K mode only.
2 LED indicator (green) ADR VLD: Lights when the receive address is enabled (not set to 0) and matches the address
embedded in the T1/E1 signal. Used in 56K mode only.
3 LED indicator (red) EQ LB: Lights when the equipment loopback is enabled.
4 LED indicator (red) PL LB: Lights when the payload loopback is enabled.
5 LED indicator (green) RX: Lights when the DS-562I is receiving data from the remote equipment
6 LED indicator (green) TX: Lights when the DS-562I is transmitting data to the remote equipment
7 LED indicator (green) SVC: Lights when the DS-562I’s service is enabled.
8 Switch SW6 This is a three position toggle switch:
UP: Sets the board to equipment loopback.
Center: Normal operation (no loopback, but can be overridden remotely
).
Down: Sets the board to payload loopback.
NOTE: If this unit is used for protective relay
i
ng applications, disable the protection
equipment before using loopbacks.
9 DIP Switch SW7 SW7-1 to SW7-6 Sets the SCB address, see Table 7.
SW7-7 Sets the DS-562I service ON or OFF:
ON(up):
Service ON (board enabled).
OFF(down):
Service OFF (board disabled).
SW7-8 Sets the DS-562I for local or remote mode:
ON(up):
Local (settings obtained from DIP switches).
OFF(down):
Remote (settings obtained from SCB).
10 DIP Switch SW1 SW1-1 to SW1-5 Sets the T1/E1 timeslot, see Table 8.
11 DIP Switch SW2 SW2-1 to SW2-6 In 56 Kbps mode, sets the transmit address, see Table 9.
12 DIP Switch SW3 SW3-1 to SW3-6 In 56 Kbps mode, sets the receive address, see Table 9.
13 DIP Switch SW4 SW4-1 Enables/disables octet timing:
ON(right):
Octet timing OFF.
OFF(left):
Octet timing ON.
SW4-2 Sets the receive clock polarity:
ON(right): Normal polarity.
OFF(left): Inverted polarity.
SW4-3 Sets the transmit clock polarity:
ON(right): Normal polarity.
OFF(left): Inverted polarity.
SW4-4 Sets receiver squelch:
ON(right): Squelch OFF.
OFF(left):
Squelch ON (DS-562I stops output to user
equipment upon loss of valid address).
SW4-7 Sets the data rate:
ON(right): 64 Kbps.
OFF(left): 56 Kbps.
SW4-8 Sets the T1/E1 transmit bus direction:
ON(right):
Transmit on “B” (receive on “A”).
OF
F(left): Transmit on “A” (receive on “B”).
14 DIP Switch SW5 SW5-1 Selects the carrier type:
ON(right): T1 carrier.
OFF(left): E1 carrier.
SW5-2 Controls the handshaking delay:
ON(right): No delay.
OFF(left):
8 microseconds delay (approx.)
SW5-3 Selects Normal Data or Inverted Data:
ON(right): Normal Data.
O
FF(left): Inverted Data.
15 Test point TP1 Transmit data
16 Test point TP2 Receive data
17 Test point TP3 Transmit clock
18 Test point TP4 Receive clock
19 Test point TP5 Ground
