INTERFACING THE IMUX 2000 WITH AN RFL 9745 USING C37.94 FIBER

OPTIC MODULES

An IMUX 2000 can be connected to an RFL 9745 equipped with a Short Haul Fiber module (107310)

as shown in Figure 12. There are no jumpers or settings on the 107310 or the MA620, however SW4-2

and SW4-3 on the DS562I must be set to the ON position.

Tx Tx Fiber Rx

Rx Rx Fiber Tx

Short

Haul

Fiber

(107310)

RFL 9745 IMUX 2000

MA-620 DS-562I

No Jumpers

Or Settings

No Jumpers

Or Settings

SW4-2 (ON)

SW4-3 (ON)

Figure 12. Interfacing the IMUX 2000 with an RFL 9745 using C37.94 Fiber Optic Modules
