RFL Electronics Inc.
I N S T R U C T I O N D A T A
RFL DS-562NC Multi-Baud Synchronous Data Module
For RFL IMUX 2000 Intelligent T1/E1 Multiplexers
(RFL Part No. 107695)
DESCRIPTION
The RFL DS-562NC Synchronous Data Module provides RFL IMUX 2000 T1/E1 Multiplexers with
synchronous full-duplex data communications at either 56 Kbps or any multiple of 64 Kbps, with a
maximum limit that is dependent upon the multiplexer type or interface adapter type. The DS-562NC
can operate up to 1.536 Mbps in T1 Multiplexers, and up to 1.984 Mbps in E1 Multiplexers; unless
CAS Mode is used, in which case the maximum rate is 1.920 Mbps. The RFL DS-562NC operates in
terminal or drop and insert systems over T1/E1 carrier lines. The RFL DS-562NC is compatible with
the older RFL DS-562I at data rates of 56 Kbps and 64 Kbps.
Features include the following:
o User-selectable data rate, 56 Kbps or Nx64 Kbps.
o Full duplex operation.
o Choice of the following interface types:
o RS-449/EIA-422, DCE or DTE
o RS-530/EIA-422, DCE or DTE
o X.21/V.11, DCE or DTE
o CCITT V.35, DCE or DTE
o G.703, Co-directional or Contra-directional
o C37.94 Short-Haul Fiber
o RFL Short Haul Fiber
o Ethernet LAN
o Octet timing support for G.703.
o Contiguous time slot assignment.
o Time Slot can be skipped for CAS multi-frame applications (E1).
o Selectable transmit/receive direction.
o Remote control configuration and status reporting using RFL NMS software.
o Equipment and payload loopbacks.
o RTS/CTS Handshaking support for V.35 and RS-449 & RS-530 interfaces
o TX/RX interface clock and data polarity settings.
RFL DS-562NC RFL Electronics Inc.
July 5, 2012 1 (973)
334-3100
