Because RFL™ and Hubbell® have a policy of continuous product improvement, we reserve the right to change designs and speciﬁcations without notice.

Table 4. Connector J1 pin assignments for the MA-408I Module Adapter

Pin No. Signal Name

1 GND - Chassis

2 TD(A) - Transmit Data (input)

9 TD(B) - Transmit Data (input)

3 RD(A) - Receive Data (output)

16 RD(B) - Receive Data (output)

Note: The clock is embedded within the Transmit and Receive data signal.

The customer interface recovers the clock provided by the MA-408I

Item Function Setting

R2 Receive data/timing (factory adjustment)

output level adjust

Connector J1

(See Table 4

for pin assign-

ments)

25-Pin

Connector

Figure 4. Controls and indicators, MA-408I Module Adapter

RFL DS-562NC RFL Electronics Inc.

July

5, 2012 12 (973) 334-3100
