RFL DS-562NC RFL Electronics Inc.
July 5, 2012 20 (973) 334-3100
Table 10. Setting the number of Timeslots (N-Baud), RFL DS-562NC
Number of
Timeslots
for T1
Number of
Timeslots
for E1
SW3-1
(16)
SW3-2
(8)
SW3-3
(4)
SW3-4
(2)
SW3-5
(1)
N/A N/A DOWN DOWN DOWN DOWN DOWN
1 1 DOWN DOWN DOWN DOWN UP
2 2 DOWN DOWN DOWN UP DOWN
3 3 DOWN DOWN DOWN UP UP
4 4 DOWN DOWN UP DOWN DOWN
5 5 DOWN DOWN UP DOWN UP
6 6 DOWN DOWN UP UP DOWN
7 7 DOWN DOWN UP UP UP
8 8 DOWN UP DOWN DOWN DOWN
9 9 DOWN UP DOWN DOWN UP
10 10 DOWN UP DOWN UP DOWN
11 11 DOWN UP DOWN UP UP
12 12 DOWN UP UP DOWN DOWN
13 13 DOWN UP UP DOWN UP
14 14 DOWN UP UP UP DOWN
15 15 DOWN UP UP UP UP
16 16 UP DOWN DOWN DOWN DOWN
17 17 UP DOWN DOWN DOWN UP
18 18 UP DOWN DOWN UP DOWN
19 19 UP DOWN DOWN UP UP
20 20 UP DOWN UP DOWN DOWN
21 21 UP DOWN UP DOWN UP
22 22 UP DOWN UP UP DOWN
23 23 UP DOWN UP UP UP
24 24 UP UP DOWN DOWN DOWN
N/A 25 UP UP DOWN DOWN UP
N/A 26 UP UP DOWN UP DOWN
N/A 27 UP UP DOWN UP UP
N/A 28 UP UP UP DOWN DOWN
N/A 29 UP UP UP DOWN UP
N/A 30 UP UP UP UP DOWN
N/A 31* UP UP UP UP UP
* The maximum timeslots available is reduced by “1” for an E1 system using CAS.
