Table 4. Time Slot Selection for RFL DS-961D module.
T
ime Slot SW2-1 SW2-2 SW2-3 SW2-4 SW2-5
1 UP UP UP UP UP
2 UP UP UP UP DOWN
3 UP UP UP DOWN UP
4 UP UP UP DOWN DOWN
5 UP UP DOWN UP UP
6 UP UP DOWN UP DOWN
7 UP UP DOWN DOWN UP
8 UP UP DOWN DOWN DOWN
9 UP DOWN UP UP UP
10 UP DOWN UP UP DOWN
11 UP DOWN UP DOWN UP
12 UP DOWN UP DOWN DOWN
13 UP DOWN DOWN UP UP
14 UP DOWN DOWN UP DOWN
15 UP DOWN DOWN DOWN UP
16 UP DOWN DOWN DOWN DOWN
17 DOWN UP UP UP UP
18 DOWN UP UP UP DOWN
19 DOWN UP UP DOWN UP
20 DOWN UP UP DOWN DOWN
21 DOWN UP DOWN UP UP
22 DOWN UP DOWN UP DOWN
23 DOWN UP DOWN DOWN UP
24 DOWN UP DOWN DOWN DOWN
Ta
ble 5. Data Rate Selection for RFL DS-961D module in 5-Channel mode
Data Rate SW3-1 SW3-2
1200 bits/second UP UP
2400 bits/second UP DOWN
4800 bits/second DOWN UP
9600 bits/second DOWN DOWN
