Table 3. Tx/Rx Time Slot Select for RFL OCUDP module.
T1
Switch Settings
Tx/Rx
Time Slot
SW2-5/SW3-5 SW2-4/SW3-4 SW2-3/SW3-3 SW2-2/SW3-2 SW2-1/SW3-1
1 OFF OFF OFF OFF OFF
2 OFF OFF OFF OFF ON
3 OFF OFF OFF ON OFF
4 OFF OFF OFF ON ON
5 OFF OFF ON OFF OFF
6 OFF OFF ON OFF ON
7 OFF OFF ON ON OFF
8 OFF OFF ON ON ON
9 OFF ON OFF OFF OFF
10 OFF ON OFF OFF ON
11 OFF ON OFF ON OFF
12 OFF ON OFF ON ON
13 OFF ON ON OFF OFF
14 OFF ON ON OFF ON
15 OFF ON ON ON OFF
16 OFF ON ON ON ON
17 ON OFF OFF OFF OFF
18 ON OFF OFF OFF ON
19 ON OFF OFF ON OFF
20 ON OFF OFF ON ON
21 ON OFF ON OFF OFF
22 ON OFF ON OFF ON
23 ON OFF ON ON OFF
24 ON OFF ON ON ON
See Note following Table 5. on equivalency between DIP-switch settings and remote control P-codes for time slot
selection.
NOTE: For SW2 and SW3, ON = RIGHT and OFF = LEFT.
Table 4. User Baud Rate Selection for RFL OCUDP module.
B
aud Rate SW4-4 SW4-3 SW4-2 SW4-1
56 kbps OFF ON ON ON
64 kbps OFF OFF OFF OFF
NOTE: For SW4, ON = RIGHT and OFF = LEFT.
