17. Set the position of SW5-8 to activate or deactivate the Channel 1 Busy Function. This switch is used to
force the off-hook condition to be either Busy or Not Busy.
Place SW5-8 to the ON position to activate the Channel 1 Busy Function (Busy).
Place SW5-8 to the OFF position to deactivate the Channel 1 Busy Function (Not Busy)
Set the position of SW9-8 to activate or deactivate the Channel 2 Busy Function. This switch is used to
force the off-hook condition to be either Busy or Not Busy.
Place SW9-8 to the ON position to activate the Channel 2 Busy Function (Busy).
Place SW9-8 to the OFF position to deactivate the Channel 2 Busy Function (Not Busy)
18. Set the position of SW7-10 to activate or deactivate the Channel 1 1kHz Test Tone.
Place SW7-10 to the ON position to activate the Channel 1, 1kHz Test Tone.
Place SW7-10 to the OFF position to deactivate the Channel 1, 1kHz Test Tone
Set the position of SW11-10 to activate or deactivate the Channel 2 1kHz Test Tone.
Place SW11-10 to the ON position to activate the Channel 2, 1kHz Test Tone
Place SW11-10 to the OFF position to deactivate the Channel 2, 1kHz Test Tone
19. Set the position of SW6-8 to enable or disable Channel 1 addressing.
Place SW6-8 to the ON position to enable Channel 1 addressing.
Place SW6-8 to the OFF position to disable Channel 1 addressing.
Set the position of SW10-8 to enable or disable Channel 2 addressing.
Place SW10-8 to the ON position to enable Channel 2 addressing.
Place SW10-8 to the OFF position to disable Channel 2 addressing.
20. Set the position of SW6-1 to SW6-7 to select the Channel 1 TX Address. The switches are labeled as
follows:
SW6-1 64
SW6-2 32
SW6-3 16
SW6-4 8
SW6-5 4
SW6-6 2
SW6-7 1
The switch settings are cumulative. For example, to set the Channel 1 TX Address = 117,
set the switches as follows:
Section Value Setting Set Value
SW6-1 64 ON 64
SW6-2 32 ON 32
SW6-3 16 ON 16
SW6-4 8 OFF 0
SW6-5 4 ON 4
SW6-6 2 OFF 0
SW6-7 1 ON 1
_______
Channel 1 TX Address setting = 117
(Note: legal TX addresses are 1 to 127)
>> text continues on page 24 <<
