Table 7. continued - Remote status messages (“S” codes)
S Code Digit(s) And Switch Equivalent Value
(1)
Description
S3
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ - - -
00001 = A
00010 = B
The printed wiring board revision.
(Not the complete assembly)
ECB REVISION LEVEL
00011 = C
etc.
B 0 0 0 0 0 0 0 0
- - - - -↑ ↑ ↑
000 to
111 Bit 0 = R110
Bit 1 = R111
BOARD MODIFICATION LEVEL
Bit 3 = R112
If any resistor is installed, the corresponding
bit will be zero
. This is used to identify custom
modifications to the assembly.
S4
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
From 00000001
to 11111111
The ACTEL firmware revision level
ACTEL REVISION LEVEL
S5
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
0 For future use only.
SUB TYPE HIGH
S6
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
1 For future use only.
SUB TYPE LOW
