SPECIFICATIONS - continued

I/O Interface: Through MA-306 module adapter

Ringing Voltage: Local (MA-306): 86 Vrms, 20 Hz

External: 50-90 Vrms, 20 to 30 Hz

Station ID: 3-digit (000 to 899)

Power Requirements: VF-8A with MA-306:

Idle Off Hook Ringing

+5V 68mA 70mA 90mA

+15V 30mA 34mA 32mA

-15V 25mA 26mA 25mA

-48V 1mA 33mA 1mA

Operating Temperature: -20

C to +55

C (-4

F to +131

F).

Humidity: 0% to 90 %, non-condensing.

RFI/EMI: C.37.90.2

MTBF: Greater than 500,000 hours per Bellcore TR-332
