Table 7. Remote configuration settings (“P” codes) for T1/E1
P Code Digit(s) And Switch
Equivalent
Value
(1)
Description
P1 B 0 0 0 0 0 0 0 0
-
- - ↑ ↑ ↑ ↑ ↑
TIME SLOT SELECT
00001 to 11000
T1 Settin
gs
From left to right, these five bits represent the binary
value of the desired time slot between 1 through 24
in a T1 network. See Table 3 for a complete list of
these values.
00001 to 11111
E1 Settin
gs
From left to right, these five bits represent the binary
value of the desired time slot between 1 through 31
in an E1 network. See Table 3 for a complete list of
these values.
B 0 0 0 0 0 0 0 0 0 Bus B disabled
- ↑ - - - - - -
BUS B ENABLE
1 Bu
s B enabled
B 0 0 0 0 0 0 0 0 0 Bus A disabled
- - ↑ - - - - -
BUS A ENABLE
1 Bus A enabled
P2 B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ - - - -
NUMBER OF RINGS
0000 to 1111 These four bits represent the binary value of the number
of rings from 0 t
o 15. See Table 4 for more information.
B 0 0 0 0 0 0 0 0
- - - - ↑ ↑ ↑ ↑
GROUP NUMBER OF
3-DIGIT STATION ID
0000 to 1000 These four bits represent the binary value of the group
number of th
e 3-digit Station ID from 0 to 8 (100’s
position). Refer to P-Code P3 below for the tens
position and units position
P3
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑
MSD LSD
MSD = most significant digit, or
value of tens position of 3-digit
Station ID.
LSD = least significant digit, or
value of units position of 3-digit
Station ID.
MSD =
0000 to 1001
LSD =
0000 to 1001
The four MSD bits represent the binary value of the
t
ens posi
tion of the 3-position Station ID.
RFL VF-8A RFL Electronics Inc.
August
6, 2010 21 (973)
334-3100
The four LSD bit
s represent the binary value of the
units
position of the 3-position Station ID.
1. These are the only legal values for setting the parameters. Setting any parameter to a value outside its specified
range will produce an unpredictable result.
