Table 6. continued - Remote configuration settings (“P” codes) for T1/E1 in enhanced mode
P Code Digit(s) And Switch Equivalent Value
(1)
Description
P4
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑
RX LEVEL CHANNEL 1
0000000 to
1111111
Sets Receive Level for channel 1 in 0.5 dB
in
crements/decrements from 0 dB center at 01000000.
Increment for lower Rx input levels to termination.
Decrement for higher Rx input levels to termination.
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
0 No delay on Channel 1 (For use in T1 only)
Sets Signaling Delay for channel 1 in T1.
SIGNALING DELAY 1
1 Delay on Channel 1 - default setting (For use in T1 only)
Sets No Delay for channel 1 in T1.
P5
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑
TX LEVEL CHANNEL 2
0000000 to
1111111
Sets Transmit Level for channel 2 in 0.5 dB
in
crements/decrements from 0 dB center at 01000000.
(40H)
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
. . . Not used.
P6
B 0 0 0 0 0 0 0 0
↑ ↑ ↑ ↑ ↑ ↑ ↑
RX LEVEL CHANNEL 2
0000000 to
1111111
Sets Transmit Level in 0.5 dB increments/decrements from
0 dB cent
er at 01000000.
Increment for lower input levels.
Decrement for higher input levels
B 0 0 0 0 0 0 0 0
↑ - - - - - - -
0 No delay on Channel 2 (Used in T1 and E1)
SIGNALING DELAY 2
1 Delay on Channel 2 - default setting (Used in T1 and E1)
1. These are the only legal values for setting the parameters. Setting any parameter to a value outside its
specified range will produce an unpredictable result.
