Table 8. continued - Remote configuration settings (“P” codes)

P Code Digit(s) And Switch Equivalent Value

(1)

Description

P05

B 0 0 0 0 0 0 0 0

↑ ↑ - - - - - -

00 40 Volts

CH1 RING VOLTAGE

01 45 Volts

10 53 Volts

11 63 Volts

B 0 0 0 0 0 0 0 0

- - ↑ - - - - -

0 DC Offset Disabled

CH1 DC OFFSET

1 DC Offset Enabled

B 0 0 0 0 0 0 0 0

- - - ↑ - - - -

0 ARD Disabled

CH1 ARD

1 ARD Enabled

B 0 0 0 0 0 0 0 0

- - - - ↑ - - -

0 20 m

CH1 LOOP CURRENT

1 41 mA

B 0 0 0 0 0 0 0 0

- - - - - ↑ ↑ -

00 None

CH1 RING DELAY

01 200/400ms

10 300/600ms

11 400/800ms

B 0 0 0 0 0 0 0 0

- - - - - - - ↑

… For future use

>> ta

ble continues on next page <<
